The conveyor belt can be transported continuously, with high efficiency and large inclination angle. The conveyor belt has the advantages of safe operation, simple use, easy maintenance and low freight. It can shorten the transportation distance, reduce the project cost and save manpower and material resources.
The main components of the belt conveyor are conveyor belt,idler and intermediate frame,pulley,driving device,tensioning device,brake device,cleaning device,protection device and unloading device.Belt conveyor is a common transportation tool in mining enterprises. It uses the belt conveyance to pull and support components and moves belt conveyor. It utilizes the inner friction and side pressure of loose material to increases the internal pressure from the pulling force in its moving direction produced by the rolling chamber in the adhesive chamber, thus increasing the internal friction. When inclination falls within certain scope, the inward friction force can ensure the stability between layers and create continuous movement. When the internal friction force between the layers is larger than the external force of the adhesive, the roller beneath the adhesive will move along with the material. When the ratio of internal force and external force meets a condition, the material flow is stable.
|
Model |
Belt Width(mm) |
Conveyor length(m) Power(kw) |
Speed(m/s) |
Capacity(t/h) |
||
|
B500 |
500 |
≤12/3 |
≤12-20/ 4-5.5 |
≤20-30/ 5.5-7.5 |
1.3-1.6 |
40-80 |
|
B650 |
650 |
≤12/4 |
≤12-20 / 5.5 |
≤20-30/ 7.5-11 |
1.3-1.6 |
80-100 |
|
B800 |
800 |
≤10/4 |
≤10-15/ 5.5 |
≤15-30/ 7.5-15 |
1.3-1.6 |
100-120 |
|
B1000 |
1000 |
≤10/5.5 |
≤10-20/ 7.5-11 |
≤20-40/ 11-22 |
1.3-2.0 |
130-150 |
|
B1200 |
1200 |
≤10/7.5 |
≤10-20/ 11 |
≤20-40/ 15-30 |
1.3-2.0 |
280-480 |
*just for reference
